Bucket elevator

Parameter

Model

Type of the buckets

Transmission force

Bucket belt line speed (m/s)

Capacity (t/h)

Powder materials

Granular materials

Powder materials =0.43

Granular materials r=0.75

TDTG26/13

DP1311 DS1311

9-23

0.8-1.2

1.2-2.2

1.2-2

6.5-9.5

TDTG26/18

DQ1814 DS1814

9-23

0.8-1.2

1.2-2.2

2-4.5

15-20

TDTG26/23

DQ2314 DS2314

9-23

0.8-1.2

1.2-2.2

5-8

16-25

TDTG36/13

DQ1311 DS1311

9-23

1.2-1.6

1.6-3

2-3

8-12

TDTG36/18

DQ1311 DS1311

9-23

1.2-1.6

1.6-3

4.5-6

16-17

TDTG36/23

DQ1311 DS1311

9-23

1.2-1.6

1.6-3

7-10

20-32

TDTG36/28

DQ2816DS2816

9-23

1.2-1.6

1.6-3

8-11

25-40

TDTG40/18

DQ1814 DS1814

9-23

1.3-1.8

1.8-3.3

5-7

22-34

TDTG50/23

DQ2314 DS2314

11-29

1.3-1.8

1.7-3.4

8-12

30-50

TDTG50/28

DQ2816DS2816

11-29

1.3-1.8

1.7-3.4

9-13

40-65

TDTG60/32

DQ2817 DS3116

13-29

1.5-2

1.8-3.5

25-35

45-70

TDTG60/38

DQ3823 DS3621

13-29

1.5-2

1.8-3.5

27-38

90-140

TDTG60/46

DQ4723 DS4621

13-29

1.5-2

1.8-3.5

32-45

120-200

TDTG80/46

DQ4723 DS4621

16-35

1.7-2.6

2.1-3.7

36-58

140-240

Item

DSTG-6

DSTG-10

DSTG-15

DSTG-20

Capacity (t/h)

5-8

8-10

12-16

18-25

Rotary speed (rpm)

60

60

34

41

Power (kw)

1.1

1.5

2.2

3

Bucket size (mm)

134X143

175X156

207X179

207X179

Belt size (mm)

200

200

200

200
