This machine can be divided into electric type, fuel type, gas type, steam type, etc. according to energy options;
According to the number of layers, there are various specifications from 3 to 7 layers;
It uses food-grade stainless steel as the main material and is equipped with functions such as hot air circulation and automatic moisture removal, which greatly improves drying efficiency and saves energy consumption;
The production process does not require manual operation. Compared with the traditional batch drying method or natural drying method, it has significant advantages in production automation, land saving, food safety, etc.

Model	HG5-5,Continuous Multi-layer dryer	HG8-5,Continuous Multi-layer dryer	HG10-5,Continuous Multi-layer dryer	HG10-7,Continuous Multi-layer dryer	Customized continuous Multi-layer dryer
Energy and heating media	Electricity/natural gas/diesel/steam/thermal oil				According to actual needs, Customized
Rated power (Electric type)	60kw	75kw	125kw	180kw
Natural gas consumption (Gas type)	3-5m³/h	5-7m³/h	8-12m³/h	10-20m³/h
Steam consumption (Steam type)	250kg/h	350kg/h	600kg/h	1000kg/h
Steam consumption (Steam type)	0.4-0.6mpa	0.4-0.6mpa	0.4-0.6mpa	0.4-0.6mpa
Dimension (LWW)	51.32m	81.32.2m	101.32.4m	101.83.2m
Main materials	Guard plates, pipes and conveyor belts are made of 304 stainless steel; The frame and chain are made of carbon steel; the insulation filler is made of aluminum silicate fiber
No. Of layers	5	5	5	7
Maximum heating temperature	120-200°C\|	120-200°C	120-200°C	120-200°C
Conveyor belt specifications	Mesh belt type/chain plate type/Teflon mesh type
Moisture removal method	Automatically dehumidify at scheduled time/humidity sensor automatically dehumidifies
Button/touch screen
