Pulse air jet deduster-Henan Gold Key Machinery Technology Co.,Ltd.

High dust filtration effect, fast discharge of purified air: dust filtration efficiency is 99.5%-99.9%, while the purified air is discharged, the hot and humid air in the machine is taken away;
Small floor space is needed,but the air volume is large, and the 0.4-0.6MPa high-pressure air source is selected to achieve strong dust cleaning effect;
Cylindrical structure, flat-bottom scraper unloading, low-pressure volute large tangential air inlet, reduce equipment resistance, reduce filter bag load, and improve dust removal effect.

Model /Parameter	TBLM26	TBLM39	TBLM52	TBLM78	TBLM104	TBLM130	TBLM156
Qty. of bags (pcs)	26	39	52	78	104	130	156
Filtering area (m²)	19.6	28.7	39.1	58.7	76.5	95.3	108.6
Number of solenoid valves (pcs)	4	6	8	10	10	12	14
Air volume (m³/h)	3530-4700	5170-6890	7040-9390	10570-14090	13770-18360	17073-23306	22315-27607
Pulse interval (s)	10~45
Pulse width (s)	0.01~0.3
Injection pressure (MPa)	0.4~0.6
Filter air speed (m/min)	3~4
Filter bag specifications (mm)	φ120×2000
Equipment resistance (Pa)	≤980

Model /Parameter	MC48	MC60	MC72	MC84	MC96	MC108	MC120
Qty .of bags (pcs)	48	60	72	84	96	108	120
Filter area (m²)	36.2	45.2	54.3	63.3	72.5	81.4	90.5
Number of solenoid valves (pcs)	8	10	12	14	16	18	20
Processing air volume (m³/h)	6520-8680	8130-108500	9800-13200	11400-15200	13000-17400	14650-19530	16290-21700
Pulse interval (s)	10~45
Pulse width (s)	0.01~0.3
Injection pressure (MPa)	0.4~0.6
Filter wind speed (m/min)	3~4
Filter bag specifications (mm)	φ120×2000
Equipment resistance (Pa)	≤980
